FS-977 Full-Size PICMG SBC with Socket 478 for Pentium 4 Processor

Equipped Gaming Embedded System
FS-977 Full-Size PICMG SBC with Socket 478 for Pentium 4 Processorn| Product ManualnProduct Drivers

Additional information

Weight

1 kg

Audio Chipset

Intel ICH4 chipset with AC97 3D audio codec

Gigabit LAN Ports

1 x Intel 82559ER 10/100/1000 LAN (Intel PRO/1000+ optional) (Dual LAN optional)

Power Consumption

5V:15.5A, 12V:5.1A – 76.7 Watts is the typical power consumption with Pentium 4 at 2.53 GHz and 256 MB of DDR

Video Chipset

Intel 845GV GMCH

Global P/N / SKU

3307521

Memory Standard

DDR 200/266/333

MFR P/N

FS-977

Manufacturer

Commell

Dimensions

W: 13.3 in. (338 mm) x D: 4.8 in. (122 mm) x H: 1.3 in. (34 mm)

Chipset

Intel Brookdale-GV chipset with 82845GV GMCH and 82801DB ICH4

BIOS

Phoenix-Award 2 Mb PnP Flash BIOS

Cost

0

Approximate Weight

2.2 lbs (1 Kg)

Serial (COM) Port

2 x RS-232C

Discontinued

Yes
