LE-575 5.25″ Fanless Embedded Controller

Equipped Gaming Embedded System
LE-575 5.25" Fanless Embedded Controller with the Intel Atom N270 processor and 4 x Intel Gigabit LAN

Additional information

Discontinued

Yes

CPU

Intel Atom Processor N270 (1.60 GHz, 512K Cache, 533 MHz FSB)

CPU Socket

Embedded

Memory Slots

1 x 200-pin SO-DIMM

Maximum Memory Supported

2GB

Memory Standard

DDR2 400 / 533 MHz

ECC Memory Supported

No

Onboard Memory

No

Dual Channel Memory Support

No

Chipset

Mobile Intel 945GSE Express Chipset with 82801GBM I/O Controller Hub (ICH7M)

BIOS

Phoenix-Award v6.00PG 8Mb SPI flash BIOS

Video Chipset

Intel Graphics Media Accelerator (GMA) 950

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

2 x SATA-150

Compact Flash

1 x Compact Flash Type I/II (solder side)

Disk On Chip (DOC)

No

Video Memory

Up to 224 MB shared with system memory

Audio Chipset

Intel ICH-7 integrated with Realtek ALC888 2-Channel HD Audio

Gigabit LAN Ports

4 x Intel 82574L 10/100/1000 Gigabit Ethernet Controllers

GPIO Port

1 x Programmable 8-bit GPIO

PCIe Socket

No

PCI Slot

1 x PCI

Mini-PCI Socket

2 x Mini-PCI Socket Type IIIA

ISA Slot

No

Serial (COM) Port

6 x COM ports – 1 x RS-232 (External I/O), 4 x RS-232 via header (cables not included) 1 x RS-232 / 422 / 485 (COM 2) (cable included)

USB Port

8 x USB 2.0 (2 x external I/O, 6 x internal via onboard header) (cables for two included only)

HDMI

No

LVDS

1 x 18-bit dual channel LVDS (secondary 18/24-bit available with Option C)

VGA

1 x VGA (external I/O)

Audio

1 x Front Panel Audio via onboard header for Line Out and Mic In (cable included)

HDTV-Out

1 x HDTV Out (cable not included)

TV-Out

1 x TV-Out (cable not included)

Approximate Weight

3 lbs (1.36 kg)

Dimensions

W: 8.0" x D: 5.75" (203 mm x 146 mm)

Operating Temperature

0°C ~ 60 °C (32 °F ~ 140 °F)

Storage Temperature

-20 ~ 85 °C (-4 ~ 185 °F)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

All popular 32-bit Operating System Software including: Linux, Windows XP / Vista / Windows 7. Not all features are guaranteed to work under every O/S

Product Notes

* Specific power consumption calculations can be performed per your request, please contact your sales representative for more information at (800)833-8999

Global P/N / SKU

3307678
