LN-D70-G -Nano-ITX Industrial Motherboard supporting the Intel Celeron J1900, Intel Celeron N2930 and the Intel Atom E3845 SoC Processors

LN-D70-G -Nano-ITX Industrial Motherboard

supporting the Intel Celeron J1900, Intel Celeron N2930 and the Intel Atom E3845 SoC Processors
The LN-D70-G Nano-ITX Industrial motherboard series is designed for the Bay Trail Intel Celeron J1900/N2930 and Atom E3845 SoC processors supporting one DDR3L SO-DIMM up to 8GB and running 1066/1333 Mhz.. The platform is based on Intel Clear Video that provides high-end media and graphics capabilities for devices that display videos, 2D/3D graphics and interactive content. In addition the LN-D70-G series supports CRT, LVDS, DVI and one Display Port to provide its advanced solutions for imaging, machine vision and digital signage applications.

Additional information

CPU

Intel Celeron J1900, Intel Celeron N2930 or Intel Atom E3845 SoC Processor

CPU Socket

FCBGA1170

Memory Slots

1 x 204-pin SO-DIMM

Maximum Memory Supported

8GB

Memory Standard

DDR3L (1.35V) 1066/1333MHz

Dual Channel Memory Support

No

BIOS

UEFI

Video Chipset

Intel Clear Video integrated HD Graphics Technology

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

2 x SATA II interface with 300MB/s(3Gb/s) transfer rate, 2 x SATA III with 600MB/s (6Gb/s) transfer rate,

Additional Onboard Storage

1 x mSATA (selectable via jumper)

Video Memory

Shared with system memory

Audio Chipset

Realtek ALC262 High Definition Audio Codec

Gigabit LAN Ports

1 x Intel i210 Gigabit LAN

GPIO Port

Onboard programmable 8-bit Digital I/O interface

PCI Express Mini-Card (Mini-PCIe)

1 x PCIE Mini card or mSATA (selectable via onboard jumper)

Serial (COM) Port

4 x RS-232 via onboard header, 1 x RS-232 and 1 x RS-232/422/485 via Rear I/O

USB Port

4 x USB (1 x USB 3.0 (XHCI) and 1 x USB 2.0 via rear I/O), 2 x USB 2.0 via onboard header

Display Port

1 x Display port (SKU's 2809047A, 2809047B and 2809047C only)

LVDS

2 x LVDS (SKU's 2809047D, 2809047E and 2809047F only)

VGA

1 x VGA (all options)

Audio

1 x Mic-In, 1 x Line Out via onboard header

HDTV-Out

via Display port (SKU's 2809047A, 2809047B and 2809047C only)

TV-Out

via Display port (SKU's 2809047A, 2809047B and 2809047C only)

Approximate Weight

0.2lbs (0.9kg)

Dimensions

W:4.72" x D:4.72" (120 mm x 120 mm)

Operating Temperature

0ºC ~ 60 ºC (32 ºF ~ 140 ºF) when using the Intel Celeron J1900 or N2930 porcessor, -40ºC ~ 75 ℃ (-40ºF ~ 167ºF) when using the Intel Atom E3845 processor

Storage Temperature

-20 ~ 85 ºC (-4 ~ 185 ºF)

Relative Humidity

10% to 90% (non condensing)

OS Software Supported

Operating System Software including: Linux, Windows 7, Windows 8, Windows 8.1 Not all features are guaranteed to work under every O/S

Global P/N / SKU

2809047

Ordering Options

LN-D70JIP-G (SKU# 2809047A):

Nano-ITX Industrial Motherboard with Intel Celeron J1900 and Onboard Display port, DVI, CRT (no LVDS)

LN-D70EIP-G (SKU# 2809047B):

Nano-ITX Industrial Motherboard with Intel Atom E3845 processor and Onboard Display port, DVI, CRT (no LVDS)

LN-D70NIP-G (SKU# 2809047C):

Nano-ITX Industrial Motherboard with Intel Celeron N2930 processor and Onboard Display port, DVI, CRT (no LVDS)

LN-D70JX2-G (SKU# 2809047D):

Nano-ITX Industrial Motherboard with Intel Celeron J1900 processor and 2 x LVDS, CRT (no Display port or DVI)

LN-D70EX2-G (SKU# 2809047E):

Nano-ITX Industrial Motherboard with Intel Atom 3845 processor and 2 x LVDS, CRT (no Display port or DVI)

LN-D70NX2-G (SKU# 2809047F):

Nano-ITX Industrial Motherboard with Intel Celeron N2930 processor and 2 x LVDS, CRT (no Display port or DVI)
