LP-175-G - PICO-ITX Embedded Motherboard with Intel Skylake (6th Gen) Core U-series Processor

Commell LP-175 – PICO-ITX Embedded Motherboard

with Intel Skylake/Kaby Lake (6th/7th Gen) Core U-series Processor
The Commell LV-175 is a Pico-ITX Embedded Motherboard supporting the 6th and 7th Generation Intel Core U-series i7, i5, i3, Celeron Mobile Processors with the Sunrise Point PCH-LP, integrated HD Graphics, DDR4 memory, Realtek High Definition Audio, Intel Gigabit LAN, Serial ATA3 with AHCI function for a system. The board provides high performance onboard graphics, 24-bit dual channel LVDS interface, DisplayPort or optional VGA , HDMI, and High Definition Audio, to meet the requirements of any multimedia application.

Additional information

CPU

Intel 6th/7th Generation Core i7 / Core i5 / Core i3 U-Series mobile processors

CPU Socket

FCBGA1356

Memory Slots

1 x 260-pin SO-DIMM

Maximum Memory Supported

16GB

Memory Standard

DDR4 1866 / 2133MHz

ECC Memory Supported

No

Dual Channel Memory Support

No

Chipset

Sunrise Point-LP

BIOS

UEFI BIOS

Video Chipset

Intel Gen9 HD Graphics

Watchdog Timer

Generates a system reset with internal timer for 1 min/s ~ 255 min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

1 x SATA3 ( 6Gbps)

Additional Onboard Storage

1 x mSATA slot via Mini-PCIe slot

Video Memory

Shared system memory

Audio Chipset

Realtek ALC262 HD Audio

Gigabit LAN Ports

1 x Intel i219-LM

PCI Express Mini-Card (Mini-PCIe)

1 x Full Size PCI Express Mini-Card Sockets (supports mSATA)

Serial (COM) Port

2 x RS-232 via onboard header (cable included)

USB Port

4 x USB (2 x USB 3.0 on rear I/O, 2 x USB 2.0 via onboard headers)

Display Port

1 x Display Port (2809076A, 2809076B, 2809076C only)

HDMI

1 x HDMI (rear I/O)

LVDS

1 x 24-bit Dual Channel LVDS

VGA

Display port to VGA adapter required (ordering options 2809076D, 2809076E, 2809076F only)

Audio

1 x Front Panel Audio via onboard header (cable included)

HDTV-Out

via HDMI and Display Port

TV-Out

via HDMI and Display Port

Approximate Weight

1.0 lbs (0.45Kg)

Dimensions

3.98" x 2.83" (100mm x 72mm)

Operating Temperature

0 ºC ~ 60ºC (32 ºF ~ 140ºF)

Storage Temperature

-20 ~ 80 ºC (-4 ~ 176 ºF)

Relative Humidity

10% to 90% (non condensing)

OS Software Supported

All popular Operating System Software including: Linux, (Windows 7, Windows 8.1, Windows 10) 64bit Not all features are guaranteed to work under every O/S

Global P/N / SKU

2809076

Commell LP-175 – PICO-ITX Embedded Motherboard

with Intel Skylake/Kaby Lake (6th/7th Gen) Core U-series Processor

The Commell LV-175 is a Pico-ITX Embedded Motherboard supporting the 6th and 7th Generation Intel Core U-series i7, i5, i3, Celeron Mobile Processors with the Sunrise Point PCH-LP, integrated HD Graphics, DDR4 memory, Realtek High Definition Audio, Intel Gigabit LAN, Serial ATA3 with AHCI function for a system.

The board provides high performance onboard graphics, 24-bit dual channel LVDS interface, DisplayPort or optional VGA , HDMI, and High Definition Audio, to meet the requirements of any multimedia application.

CONTACT US NOW

In stock

Board *

Memory

mSATA Drive (Only available when not using Mini-PCIe card in slot)

2.5″ Hard Drive(HDD) / Solid State Drive (SSD)

Operating System (Only available if a storage device is selected from above)

Addon Card(s) (Only available when not using Mini-PCIe slot for mSATA)

Testing (only available if memory is included at the time of purchase)

SKU: 2809076 Tags:

Additional information

CPU

Intel 6th/7th Generation Core i7 / Core i5 / Core i3 U-Series mobile processors

CPU Socket

FCBGA1356

Memory Slots

1 x 260-pin SO-DIMM

Maximum Memory Supported

16GB

Memory Standard

DDR4 1866 / 2133MHz

ECC Memory Supported

No

Dual Channel Memory Support

No

Chipset

Sunrise Point-LP

BIOS

UEFI BIOS

Video Chipset

Intel Gen9 HD Graphics

Watchdog Timer

Generates a system reset with internal timer for 1 min/s ~ 255 min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

1 x SATA3 ( 6Gbps)

Additional Onboard Storage

1 x mSATA slot via Mini-PCIe slot

Video Memory

Shared system memory

Audio Chipset

Realtek ALC262 HD Audio

Gigabit LAN Ports

1 x Intel i219-LM

PCI Express Mini-Card (Mini-PCIe)

1 x Full Size PCI Express Mini-Card Sockets (supports mSATA)

Serial (COM) Port

2 x RS-232 via onboard header (cable included)

USB Port

4 x USB (2 x USB 3.0 on rear I/O, 2 x USB 2.0 via onboard headers)

Display Port

1 x Display Port (2809076A, 2809076B, 2809076C only)

HDMI

1 x HDMI (rear I/O)

LVDS

1 x 24-bit Dual Channel LVDS

VGA

Display port to VGA adapter required (ordering options 2809076D, 2809076E, 2809076F only)

Audio

1 x Front Panel Audio via onboard header (cable included)

HDTV-Out

via HDMI and Display Port

TV-Out

via HDMI and Display Port

Approximate Weight

1.0 lbs (0.45Kg)

Dimensions

3.98" x 2.83" (100mm x 72mm)

Operating Temperature

0 ºC ~ 60ºC (32 ºF ~ 140ºF)

Storage Temperature

-20 ~ 80 ºC (-4 ~ 176 ºF)

Relative Humidity

10% to 90% (non condensing)

OS Software Supported

All popular Operating System Software including: Linux, (Windows 7, Windows 8.1, Windows 10) 64bit Not all features are guaranteed to work under every O/S

Global P/N / SKU

2809076
