Additional information
| CPU | Arrow Lake-S Ultra 200S Series CPUs |
|---|---|
| Chipset | Intel® W880 |
| Memory Type | DDR5 SODIMM/CSODIMM, unbuffered and ECC supported |
| Memory Slots | 2 |
| Maximum Memory Supported | Ultra 9/7 supports up to 6400MHz, 96GB; Ultra 5 supports up to 5600MHz, 96GB |
| Integrated Graphics | Integrated Intel Xe LPG Graphics |
| Watchdog Timer | Software Programmable Supports 256 Levels System Reset |
| TPM | Supports Discrete TPM2.0 (with Optional CFM Module) |
| Instant Reboot | Supports 0.2sec Instant Reboot Technology |
| External Fan Connector | 1x External FAN Connector, 4-pin Terminal Block (Support Smart Fan by BIOS) |
| Video | 1x VGA, 1 x DP 4K, 1x HDMI 4K |
| LAN Ports | 2 x 2.5GbE, Intel i226 Chipset LAN |
| Serial ATA (SATA) | 2x 2.5" Front Accessible SATA 3.0 Bays |
| Serial (COM) Port | 4x RS-232,422,485 with Auto Flow Control (Supports 5V/12V), DB9 |
| Audio | Realtek ALC888 HD Audio |
| RAID | Supports RAID 0/1/5/10 |
| M.2 Interface | 1x M.2 Key B Type 3042/3052 Socket (PCIe Gen 3×2 / USB3.2 Gen1x1 / SATA), Supports 5G / GNSS / Storage / Add-on Card Expansion; 1x M.2 Key B Type 2242 Socket (PCIe Gen 4×2 / USB2.0 / SATA), Supports Storage / Add-on Card Expansion; 1x M.2 Key E Type 2230 Socket (PCIe Gen 3×2 /USB 2.0), Supports Bluetooth/Wireless/Storage/Intel CNVi Module Expansion |
| SIM | 1x SIM Socket |
| CMI (See Ordering Options) | 2x High Speed CMI Interface for optional CMI Module Expansion; 1x Low Speed CMI Interface for optional CMI Module Expansion |
| CFM (See Ordering Options) | 1x CFM IGN Interface for optional CFM-IGN Module Expansion; 1x CFM-TPM Interface for optional CFM-TPM Module Expansion |
| Power Requirement | 9 ~ 48V DC Input 3-Pin Terminal Block |
| Reverse Power Input Protection | Yes |
| Over Voltage Protection | Protection Range: 51~58V; Protection Type: shut down operating voltage, re-power on at the preset level to recover |
| Remote Power | 1x Remote Power On/Off, 2-pin Terminal Block; 1 x Remote Power LED, 2-pin Terminal Block |
| Dimensions | 242.2 x 173 x 75mm |
| Mechanical Construction | Extruded Aluminum with Heavy Duty Metal |
| Physical Design | Fanless, Cableless, Jumper-Less, Unibody Design |
| MTBF | 332,808 Hours |
| Operating Temperature | 35W Processor: -40 ~ 70°C (-40 ~ 158°F), 65W Processor with External Fan Kit: -40 ~ 50°C (-40 ~ 122°F) |
| Storage Temperature | -40°C ~ 85°C (-40°F ~ 185°F) |
| Relative Humidity | 95%@60°C (non-Condensing) |
| Shock | MIL-STD-810H |
| Vibration | MIL-STD-810H |
| EMC | CE, UKCA, FCC, ICES-003 Class A |
| EMI | CISPR 32 Conducted & Radiated: Class A; EN/BS EN 50121-3-2 Conducted & Radiated: Class A; EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A; EN/BS EN61000-3-3 Voltage fluctuations & flicker; FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A |
| EMS | EN/IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV; EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 20 V/m; EN/IEC 61000-4-4 EFT: AC Power: 2 kV; Signal: 2 kV; EN/IEC 61000-4-5 Surges: AC Power: 2 kV; EN/IEC 61000-4-6 CS: 10V; EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m; EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz |
| Railway | EMC: EN 50155: 2021 Clause 4.4.6, 13.4.9; EN 50121-1 : 2017; EN 50121-3-2: 2016 + A1: 2019 |
| Safety | UL, cUL, CB, IEC, EN 62368-1 |
| Fire Protection | EN 45545-2 |
| Operating System Support | Windows 11; Ubuntu Linux 24.04 |
| Global P/N / SKU | 1708644 |
