IMB-X1240-WV – Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Processor Support

This Mini-ITX motherboard with Intel® 14th/13th/12th Gen Processor Support comes packed with next gen features such as DDR5 SO-DIMM memory slots, PCIe x16 Gen5, M.2 NVMe, 12~28V DC-In, and 4 x GPI 4 x GPO GPIO pins. This small but powerful board is a great choice for your next application where long term availability is needed.

Additional information

CPU

Intel® 14th/13th/12th Gen Core™ Processors up to 65W

Chipset

Intel® W680

Memory Type

DDR5 4800/5600 MHz* ECC/non-ECC *Actual memory frequency depends on the CPU types and DRAM modules.

Memory Slots

2

Maximum Memory Supported

64GB

Integrated Graphics

Intel® UHD Graphics

Audio

Realtek ALC897 HD

Video

2 x HDMI 2.0b, 1 x DP 1.4a, 1 x LVDS, 1 x eDP 1.4b

LAN Ports

Intel® I226V 2.5GbE LAN, Intel® I219LM Gigabit LAN supports vPro

Serial ATA (SATA)

2 x SATAIII supports Intel® VMD RAID 0/1

GPIO Interface

4 x GPI, 4 x GPO

TPM

TPM 2.0 onboard IC

Watchdog Timer

256 segments (0-255 sec/min)

Extended Interface

1 x M.2 (Key M, 2242/2280) PCIe Gen4 x4, 1 x M.2 (Key M, 2242) PCIe Gen4 x4 SATA3, 1 x M.2 (Key E, 2230) PCIe x1 USB/Wireless, 1 x M.2 (Key B, 3042/3052) PCIe x1 USB 3.2/USB 2.0/4G/5G, 1 x PCIe x16

Rear I/O

2 x HDMI 2.0b, 1 x DP 1.4a++, 1 x 2.5 Gigabit LAN, 1 x 1 Gigabit LAN,4 x USB 3.2 (Gen2), Mic-in Line-out

Internal I/O

2 x USB 3.2, 4 x USB 2.0, 2 x COM, 4 x GPI 4x GPO, 1 x LVDS, 1 x eDP, 1 x SATA PWR Out

Power Requirement

12~28V DC-In with 4-pin wafer PWR cable or DC Jack (Screw type)

Operating Temperature

0°C ~ 70°C (32°F ~ 158°F)

Storage Temperature

-40°C ~ 85°C (-40°F ~ 185°F)

Relative Humidity

5 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit, Windows 11 64-bit

Global P/N / SKU

2809175

Ordering Options

IMB-X1240-WV (SKU# 2809175):
Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Core™ Processor support (up to 65W)

*If motherboard ambient temp. is over 55ºC, a memory thermal solution should be added to avoid thermal issues.

Downloads

Datasheet

Ordering Options

IMB-X1240-WV (SKU# 2809175): Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Core™ Processor support (up to 65W) *If motherboard ambient temp. is over 55ºC, a memory thermal solution should be added to avoid thermal issues.

IMB-X1240-WV – Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Processor Support

This Mini-ITX motherboard with Intel® 14th/13th/12th Gen Processor Support comes packed with next gen features such as DDR5 SO-DIMM memory slots, PCIe x16 Gen5, M.2 NVMe, 12~28V DC-In, and 4 x GPI 4 x GPO GPIO pins. This small but powerful board is a great choice for your next application where long term availability is needed.

CONTACT US NOW

Board

CPU

Memory

M.2 SSD

2.5″ SATA SSD

Operating System (Only available if a storage device is selected from above)

Testing (only available if CPU and Memory is included at the time of purchase)

SKU: 2809175 Tags: Digital Signage, Internet of Things (IoT), Mini-ITX, POS-Kiosk, small form factor

Additional information

CPU

Intel® 14th/13th/12th Gen Core™ Processors up to 65W

Chipset

Intel® W680

Memory Type

DDR5 4800/5600 MHz* ECC/non-ECC *Actual memory frequency depends on the CPU types and DRAM modules.

Memory Slots

2

Maximum Memory Supported

64GB

Integrated Graphics

Intel® UHD Graphics

Audio

Realtek ALC897 HD

Video

2 x HDMI 2.0b, 1 x DP 1.4a, 1 x LVDS, 1 x eDP 1.4b

LAN Ports

Intel® I226V 2.5GbE LAN, Intel® I219LM Gigabit LAN supports vPro

Serial ATA (SATA)

2 x SATAIII supports Intel® VMD RAID 0/1

GPIO Interface

4 x GPI, 4 x GPO

TPM

TPM 2.0 onboard IC

Watchdog Timer

256 segments (0-255 sec/min)

Extended Interface

1 x M.2 (Key M, 2242/2280) PCIe Gen4 x4, 1 x M.2 (Key M, 2242) PCIe Gen4 x4 SATA3, 1 x M.2 (Key E, 2230) PCIe x1 USB/Wireless, 1 x M.2 (Key B, 3042/3052) PCIe x1 USB 3.2/USB 2.0/4G/5G, 1 x PCIe x16

Rear I/O

2 x HDMI 2.0b, 1 x DP 1.4a++, 1 x 2.5 Gigabit LAN, 1 x 1 Gigabit LAN,4 x USB 3.2 (Gen2), Mic-in Line-out

Internal I/O

2 x USB 3.2, 4 x USB 2.0, 2 x COM, 4 x GPI 4x GPO, 1 x LVDS, 1 x eDP, 1 x SATA PWR Out

Power Requirement

12~28V DC-In with 4-pin wafer PWR cable or DC Jack (Screw type)

Operating Temperature

0°C ~ 70°C (32°F ~ 158°F)

Storage Temperature

-40°C ~ 85°C (-40°F ~ 185°F)

Relative Humidity

5 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit, Windows 11 64-bit

Global P/N / SKU

2809175

Ordering Options

IMB-X1240-WV (SKU# 2809175):
Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Core™ Processor support (up to 65W)

*If motherboard ambient temp. is over 55ºC, a memory thermal solution should be added to avoid thermal issues.

Downloads

Datasheet

Ordering Options

IMB-X1240-WV (SKU# 2809175): Mini-ITX Motherboard with Intel® 14th/13th/12th Gen Core™ Processor support (up to 65W) *If motherboard ambient temp. is over 55ºC, a memory thermal solution should be added to avoid thermal issues.
