IMB-X1715 – ATX Motherboard with Intel® W880 Chipset for Intel® Core™ Ultra Processors

The IMB-X1715 is a modern full-size ATX motherboard with support for Intel® Arrow Lake-S Core™ Ultra Processors. Equipped with the powerful Intel® W880 chipset, this board can run a wide array of PCIe expansion cards simultaneously making it an adaptable and customizable industrial solution. The IMB-X1715 also features quad-display support, allowing for deployment across sectors.

Additional information

CPU

Intel® Core™ processors (Arrow Lake-S), up to 125W

CPU Socket

LGA1851

Memory Type

288-pin DDR5 ECC/non-ECC 5600MHz DIMM

Memory Slots

4

Maximum Memory Supported

192GB

Chipset

Intel® W880

Integrated Graphics

Intel® Xe LPG Graphics

Watchdog Timer

256 Segments, 0, 1, 2, …255sec

Video

2 x HDMI 2.1 TMDS, 1 x DisplayPort 1.4a++, 2 x Thunderbolt 4 (Supports DisplayPort 2.1)

LAN Ports

1 x Intel® I219LM GbE vPro, 1 x Intel® I210AT GbE

Serial ATA (SATA)

4 x SATA III

Storage

1 x M.2 M-Key 2242/2280/22110/25110 PCIe Gen5 x4, 1 x M.2 M-Key 2242/2280 PCIe Gen4 x4

RAID

Intel® VMD RAID 0/1/5/10 **supported by identical interface (PCIe or SATA) PCIe interface: M.2 Key B + M.2 Key M SATA interface: SATA port

GPIO Interface

8 x GPI, 8 x GPO (shared with LPT header)

TPM

TPM 2.0 onboard IC

Extended Interface

2 x PCIe Gen5 Slots (single at x16; dual at x8/x8) (PCIE1: Support Riser card x8/x8), 3 x PCIe Gen4 x4, 2 x PCIe Gen4 x1, 1 x M.2 E-Key 2230 PCIe Gen4 x1, 1 x M.2 B-Key 3042/3052 PCIe Gen4 x 1

Rear I/O

2 x HDMI, 1 x DP, 2 x LAN, 5 x USB 3.2 Gen2, 1 x USB4/Thunderbolt 4 1 x Line-In, 1 x Line-Out, 1 x Mic-In, 2 x RS-232/422/485

Internal I/O

2 x USB 3.2 Gen1 Headers, 1 x USB 3.2 Gen2 Vertical Connector, 1 x USB4/Thunderbolt 4, 1 x RS-232/TTL 5V/ccTalk, switch by Jumper setting, 3 x RS-232, 1 x LPT/GPIO, 1 x Thunderbolt Header

Audio

Realtek® ALC897 HD Audio

Power Requirement

ATX Power (24+8+8-pin)

Dimensions

12" x 9.6" (305mm x 244mm)

Operating Temperature

-20 ~ 70 °C (-4 ~ 158 °F)

Storage Temperature

-40 ~ 85 °C (-40 ~ 185 °F)

Relative Humidity

5 ~ 90%

OS Software Supported

Windows 10 64-bit, Windows 11 64-bit

Global P/N / SKU

2809195

Ordering Options

IMB-X1715 (SKU# 2809195):
ATX Motherboard with Intel® W880 Chipset

Downloads

Datasheet

Ordering Options

IMB-X1715 (SKU# 2809195): ATX Motherboard with Intel® W880 Chipset
