LP-17B – Pico-ITX Mini Board Equipped with Intel® Core™ Meteor Lake Ultra U Processor

The LP-17B is a Pico-ITX form factor board equipped with an Intel® Core™ Meteor Lake Ultra U Processor, allowing for power and efficiency with a minuscule footprint. It features the Advanced Intel® AI Boost NPU for low-power AI acceleration and CPU/GPU offload. The LP-17B is a highly capable and cutting-edge industrial mini board solution.

Additional information

CPU

Intel® Core™ Meteor Lake Ultra U Processors

Memory Type

262-pin DDR5 5600MHz SO-DIMM

Memory Slots

1

Maximum Memory Supported

32GB

Integrated Graphics

Intel® Graphics

Serial ATA (SATA)

1 x SATA III

Watchdog Timer

Generates a system reset with internal timer for 1 min/s ~ 255 min/s

Video

1 x HDMI, 1 x DisplayPort++, 1 x USB Type-C (DP Alt. Mode)

Audio

Realtek ALC888S HD Audio

LAN Ports

1 x Intel® I226LM 2.5GbE, 1 x Intel® I226V 2.5GbE

Extended Interface

1 x M.2 E-Key 2230 for Wi-Fi and Bluetooth, 1 x M.2 M-Key 2280 PCIe x4 Gen4 or SATA

Internal I/O

1 x SATA III, 2 x USB 2.0, 1 x Audio Amplifier, 1 x GPIO, 1 x RS-232/422/485, 1 x eDP/LVDS (with optional module, contact sales for more details)

Rear I/O

1 x HDMI, 1 x DisplayPort++, 1 x USB Type-C (DP Alt. Mode), 2 x LAN, 1 x USB 3.2 Gen 2

Power Requirement

DC input 12V±5%

Dimensions

3.94" x 2.83" (100mm x 72mm)

Operating Temperature

0 ~ 60° C (32 ~ 140° F)

Storage Temperature

-20 ~ 80 °C (-4 ~ 176 °F)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 11 64-bit

Global P/N / SKU

2809190

Ordering Options

LP-17B7 (SKU# 2809190A):
Pico-ITX Motherboard with Intel® Core™ Ultra 7 165U Processor

LP-17B5 (SKU# 2809190B):
Pico-ITX Motherboard with Intel® Core™ Ultra 5 135U Processor

Downloads

Datasheet

Ordering Options

LP-17B7 (SKU# 2809190A): Pico-ITX Motherboard with Intel® Core™ Ultra 7 165U Processor LP-17B5 (SKU# 2809190B): Pico-ITX Motherboard with Intel® Core™ Ultra 5 135U Processor

LP-17B – Pico-ITX Mini Board Equipped with Intel® Core™ Meteor Lake Ultra U Processor

The LP-17B is a Pico-ITX form factor board equipped with an Intel® Core™ Meteor Lake Ultra U Processor, allowing for power and efficiency with a minuscule footprint. It features the Advanced Intel® AI Boost NPU for low-power AI acceleration and CPU/GPU offload. The LP-17B is a highly capable and cutting-edge industrial mini board solution.

CONTACT US NOW

Board *

Memory

M.2 SSD

2.5″ SATA SSD

Operating System (Only available if a storage device is selected from above.)

Testing (Only available if memory is included at time of purchase.)

SKU: 2809190 Tags: embedded, Meteor Lake, mini boards, Pico-ITX, small form factor

Additional information

CPU

Intel® Core™ Meteor Lake Ultra U Processors

Memory Type

262-pin DDR5 5600MHz SO-DIMM

Memory Slots

1

Maximum Memory Supported

32GB

Integrated Graphics

Intel® Graphics

Serial ATA (SATA)

1 x SATA III

Watchdog Timer

Generates a system reset with internal timer for 1 min/s ~ 255 min/s

Video

1 x HDMI, 1 x DisplayPort++, 1 x USB Type-C (DP Alt. Mode)

Audio

Realtek ALC888S HD Audio

LAN Ports

1 x Intel® I226LM 2.5GbE, 1 x Intel® I226V 2.5GbE

Extended Interface

1 x M.2 E-Key 2230 for Wi-Fi and Bluetooth, 1 x M.2 M-Key 2280 PCIe x4 Gen4 or SATA

Internal I/O

1 x SATA III, 2 x USB 2.0, 1 x Audio Amplifier, 1 x GPIO, 1 x RS-232/422/485, 1 x eDP/LVDS (with optional module, contact sales for more details)

Rear I/O

1 x HDMI, 1 x DisplayPort++, 1 x USB Type-C (DP Alt. Mode), 2 x LAN, 1 x USB 3.2 Gen 2

Power Requirement

DC input 12V±5%

Dimensions

3.94" x 2.83" (100mm x 72mm)

Operating Temperature

0 ~ 60° C (32 ~ 140° F)

Storage Temperature

-20 ~ 80 °C (-4 ~ 176 °F)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 11 64-bit

Global P/N / SKU

2809190

Ordering Options

LP-17B7 (SKU# 2809190A):
Pico-ITX Motherboard with Intel® Core™ Ultra 7 165U Processor

LP-17B5 (SKU# 2809190B):
Pico-ITX Motherboard with Intel® Core™ Ultra 5 135U Processor

Downloads

Datasheet

Ordering Options

LP-17B7 (SKU# 2809190A): Pico-ITX Motherboard with Intel® Core™ Ultra 7 165U Processor LP-17B5 (SKU# 2809190B): Pico-ITX Motherboard with Intel® Core™ Ultra 5 135U Processor
