LV-6715 – Mini ITX Motherboard with Intel®Alder Lake H Core i7-12800HE or i7-13800HE Processor Onboard

This Intel® Alder Lake Mini-ITX Motherboard features two Core i7 processor options. With multiple M.2 slots for Wifi, Bluetooth, storage and expansion, this board is ideal for Automation, IoT, Surveillance, and other Industrial uses. Although this board has Intel's® IRIS® XE Graphics onboard with 2 x HDMI, 2 x DP,  and 1 x HDMI/DVI or  onboard LVDS,  it also allows for a PCIe x16 slot for advanced graphics cards. There are two options for power  - either standard 24-pin ATX or 4-pin DC 9~35V. Multiple USB, COM and 2 x LAN add to the many features of this unique 12th / 13th Gen Mini-ITX Motherboard.

Additional information

CPU

Intel ®Core i7-13800HE, Intel® Core i7-12800HE

Memory Type

2 x DDR5 SO-DIMM 4800 MHz up to 64 GB, Support Non-ECC unbuffered memory

Memory Slots

2

Maximum Memory Supported

64GB

Audio

Realtek ALC888S HD Audio

Integrated Graphics

Intel® Iris® Xe Graphics

Watchdog Timer

Generates a system reset with internal timer for 1 min/s ~ 255min/s

Serial ATA (SATA)

2 x SATA3 (mSATA and SATA3-2 can't be use at the same time)

Video

1 x LVDS (mSATA and SATA2 can't be used at the same time), 1 x DVI/HDMI, 2 x HDMI, 2 x Display Port

TPM

Yes; fTPM

LAN Ports

1 x Intel® I219-LM Gigabit PHY LAN (supports Intel® AMT 16.0), 2x Intel® I226-LM Gigabit LAN (up to 2.5 GbE)

Extended Interface

1 x MiniPCIe (supports mSATA when SATA3-2 is not used), 2 x M.2 2280 M-Key (supports PCIe Gen4 for NVMe), 1 x M.2 2230 E-Key (for Wi-Fi and Bluetooth), 1 x PCIe x16 Slot (supports Gen4 X8)

Internal I/O

2 x SATA3, 4 x RS232, 2 x USB2.0, 1 x GPIO, 1 x SMBus, 1 x Audio, 1 x LAN, 1 x LVDS, 1 x LCD inverter, 1 x DVI/HDMI

Rear I/O

4 x USB3.2 Gen2, 2 x USB2.0, 2 x LAN, 2 x RS232/422/485, 1 x Audio, 2 x HDMI, 2 x DisplayPort

Power Requirement

Standard 24-pin ATX power supply or 4-pin 9~35V

Dimensions

170 mm x 170 mm

Operating Temperature

0 ~ 60° C (32 ~ 140° F)

Storage Temperature

-20 ~ 80 °C (-4 ~ 176 °F)

Relative Humidity

10%~90%, non-condensing

OS Software Supported

Windows 10 Professional 64-bit, Windows 11

Global P/N / SKU

2809153

Ordering Options

LV-6715H7 – With Core i7-12800HE and Cooler Fan
LV-6715R7 – With Core i7-13800HE and Cooler Fan



Add ADP-3355 for VGA through the Display Port

Add ADP-3460 for 2nd LVDS through the Display Port

Downloads

Datasheet

Ordering Options

LV-6715H7 – With Core i7-12800HE and Cooler Fan LV-6715R7 – With Core i7-13800HE and Cooler Fan   Add ADP-3355 for VGA through the Display Port Add ADP-3460 for 2nd LVDS through the Display Port

LV-6715 – Mini ITX Motherboard with Intel®Alder Lake H Core i7-12800HE or i7-13800HE Processor Onboard

This Intel® Alder Lake Mini-ITX Motherboard features two Core i7 processor options. With multiple M.2 slots for Wifi, Bluetooth, storage and expansion, this board is ideal for Automation, IoT, Surveillance, and other Industrial uses. Although this board has Intel’s® IRIS® XE Graphics onboard with 2 x HDMI, 2 x DP,  and 1 x HDMI/DVI or  onboard LVDS,  it also allows for a PCIe x16 slot for advanced graphics cards. There are two options for power  – either standard 24-pin ATX or 4-pin DC 9~35V. Multiple USB, COM and 2 x LAN add to the many features of this unique 12th / 13th Gen Mini-ITX Motherboard.

CONTACT US NOW

Board

Memory

Storage

WiFi/BT Card

Operating System (Only available if a storage device is selected from above)

Testing (only available if memory is included at the time of purchase)

SKU: 2809153 Tags: Alder Lake, Industrial Automation, Internet of Things (IoT), mini boards, Mini-ITX, small form factor
