Additional information
| CPU | ntel® Core™ Ultra Series 3 Processors (PTL-H Platform) |
|---|---|
| CPU Socket | FCBGA2540 |
| Memory Slots | 2, DDR5 SO-DIMM 7200MHz |
| Maximum Memory Supported | 128GB |
| Chipset | Intel® W880 |
| Audio | Realtek ALC888S HD Audio |
| Video | 18/24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply, DisplayPort 1.4a, HDMI 2.1 |
| Watchdog Timer | Generates a system reset with internal timer for 1 min/s ~ 255 min/s |
| LAN Ports | 2 x Intel® 2.5G LAN, 1 x Intel® 10G LAN |
| Storage | 1 x M.2 Key M 2280 support PCIe Gen4 for NVMe, 1 x M.2 Key M 2280 support PCIe Gen5 for NVMe |
| GPIO Interface | Onboard programmable 8-bit Digital I/O interface |
| Extended Interface | 1 x M.2 Key E 2230 for Wi-Fi and Bluetooth, 1 x PCIe x16 slot support PCIe Gen5 x8 |
| Rear I/O | 3 x USB3.2 Gen2, 1 x USB2.0, 2 x LAN, 2 x RS232/422/485, 1 x HDMI, 1 x DisplayPort ++, 1 x Line-in, 1 x Line-out, 1 x MIC-in, 1 x Type-C (DP Alt Mode). |
| Internal I/O | 4 x RS232, 2 x USB2.0, 1 x 10G LAN, 1 x GPIO, 1 x SMBus, 1 x Audio (MIC-in & Line-out), 1 x LCD inverter, 1 x LVDS |
| Power Requirement | Standard 24-pin ATX power supply (20-pin is compatible) or DC 9~35V full range support |
| Dimensions | 6.69" x 6.69" (170mm x 170mm) |
| Operating Temperature | 0 ~ 60° C (32 ~ 140° F) |
| Storage Temperature | -20 ~ 80 °C (-4 ~ 176 °F) |
| Relative Humidity | 10 ~ 90% (non-condensing) |
| OS Software Supported | Windows 11 64-bit |
| Global P/N / SKU | 2809208 |
