MAS1015 – 10.1″ Automation Rugged Windows Mobile Tablet PC with Intel® N100 Processor

The MAS1015 is a 10.1" rugged tablet PC equipped with the Intel® Alder Lake-N N100 processor. With 1000 nits of brightness, 1.22m drop resistance, and IP65 water resistance, this tablet is ideal for use in industrial environments. The MAS1015 has optional accessories for expansion allowing for deployment in a variety of sectors like logistics, inventory management, and warehouse operations.

Additional information

CPU

Intel® N100 Processor

Memory Type

LPDDR5

Maximum Memory Supported

8GB

Integrated Graphics

Intel® UHD Graphics

Video

1 x HDMI 2.0 Mini

Storage

128GB eMMC

Display

10.1 inch IPS LCD

Resolution

1920 x 1200

Brightness

1000 nits

Touch Panel

10 point G+G capacitive touch screen, Hardness Above 7H, Scratch-Resistant, Supports Glove Touch

WiFi

WIFI6 802.11(a/b/g/n/acR2/ax 1×1) frequency 2.4G + 5.8G Dual-band WIFI (Intel AX101)

4G

LTE FDD: B1/B3/B5/B7/B8/B20/B28, LTE-TDD B38/B40/B41

Bluetooth

BT5.2

GPS

GPS+Glonass, (Optional GPS+Beidou)

Camera

Front 5.0MP; Rear 8.0MP

Speaker

2 x 1W Waterproof Speakers

Color

Caesious

Sensors

G-Sensor

Battery

Removable Polymer Lithium-ion Battery 7.6V/5000mAh

Battery Life

5.5 hrs (Default 50% Volume, Default 50% Volume Brightness, Play 1080P HD Video)

IP Rating

IP65

Drop Test

1.22m Drop Resistance

I/O

1 x USB 3.0 Type-A, 1 x USB 3.0 Type-C (Data & Charging), 1 x SIM, 1 x TF Card, 1 x HDMI Mini, 1 x 12-pin Pogo Pin, 1 x 3.5mm Audio, 1 x 12V DC Jack, 1 x RJ45 LAN (optional with USB2.0 or RS-232)

Power Requirement

12V DC Input Jack

Dimensions

10.82" x 7.43" x 0.874" (274.9mm x 188.7mm x 22.2mm)

Weight

1.13 kg (2.49 lbs)

Operating Temperature

-20 ~ 60°C (-4 ~ 140°F)

Storage Temperature

-30 ~ 70 ºC (-22 ~ 158 ºF)

Relative Humidity

95% RH non-condensing

OS Software Supported

Windows 10 IoT Enterprise LTSC 2021, Windows 11

Certification

CE/ FCC/CCC/ MIL-STD-810H

Global P/N / SKU

2911110

Ordering Options

MAS1015 (SKU# 2911110):
10.1″ Automation Rugged Windows Mobile Tablet PC with Intel® N100 Processor

Optional Accessories (Ask sales for more details)
ADOCK50 – Docking Station w/ 1 x LAN, 1 x COM, 1 x USB Type-A, 1 x DC Jack
ABAT805 – Removable Battery
ACARMA1 – Mounting Holder w/ 1 x LAN, 1 x COM, 2 x USB Type-A, 1 x DC Jack
ACARC18 – Vehicle Charger (19V/3.42A) DC In 5.5mm
ADA12D0 – Adapter 12V/4A DC In 5.5mm

Downloads

Datasheet

Ordering Options

MAS1015 (SKU# 2911110): 10.1″ Automation Rugged Windows Mobile Tablet PC with Intel® N100 Processor Optional Accessories (Ask sales for more details) ADOCK50 - Docking Station w/ 1 x LAN, 1 x COM, 1 x USB Type-A, 1 x DC Jack ABAT805 - Removable Battery ACARMA1 - Mounting Holder w/ 1 x LAN, 1 x COM, 2 x USB Type-A, 1 x DC Jack ACARC18 - Vehicle Charger (19V/3.42A) DC In 5.5mm ADA12D0 - Adapter 12V/4A DC In 5.5mm
