MD711-SU – 6th Gen Intel® Core Processor Fanless Medical Computing System

The MD711-SU is the perfect embedded fanless system for your medical computing needs. With a medical-grade anti-microbial finish and downward fin design, cleaning is easy and inhibits bacterial growth. This system has 4kV isolation on LAN, COM, and USB 2.0 ports for transmission without noise and seamless integration with medical equipment. The MD711-SU has vibration resistance and the ability to output to 2 displays simultaneously.

Additional information

CPU

Intel 6th Gen Core i5/i7 Mobile Processor

Memory Type

260-pin DDR4 2133 MHz SO-DIMM

Memory Slots

2

Maximum Memory Supported

32 GB

Integrated Graphics

Intel® HD Graphics

Watchdog Timer

Programmable via software from 1 to 255 seconds

Serial ATA (SATA)

2 x SATA III

Video

1 x DVI, 1 x DP/HDMI

LAN Ports

1 x Intel® I219-LM Gigabit PHY LAN, 1 x Intel® I210-AT Gigabit LAN

Extended Interface

1 x PCIe X 16 slot, 1 x Full-size Mini-PCIe, 1 x M.2 (2242 B Key)

Rear I/O

2 x LAN, 2 x RS-232, 4 x USB 3.0, 2 x USB 2.0, 1 x DP/HDMI, 1 x DVI-D, 1 x Line-Out, 1 x Mic-In, 1 x Wi-Fi Antenna Hole

Audio

Realtek ALC888 HD Audio

Power Requirement

DC input 9~36V

Dimensions

182mm x 97.6mm x 200mm

Operating Temperature

0 ~ 40°C (32 ~ 104°F) with 0.7m/s air flow

Storage Temperature

-20 ~ 85 °C (-4 ~ 185 °F)

Relative Humidity

5 ~ 90% (non-condensing)

OS Software Supported

Windows 7 (32/64-bit), Windows 8.1 (64-bit), Windows 10 (64-bit), WES 7 (32/64-bit), WES 8.1 (64-bit)

Global P/N / SKU

1708622

Ordering Options

750-MD7110-000G (SKU# 1708622A):
Intel® Core i5-6300U, 1 DP, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16

750-MD7110-100G (SKU# 1708622B):
Intel® Core i7-6600U, 1 DP, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16

750-MD7110-200G (SKU# 1708622C):
Intel® Core i5-6300U, 1 HDMI, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16

750-MD7110-300G (SKU# 1708622D):
Intel® Core i7-6600U, 1 HDMI, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16

Ordering Options

750-MD7110-000G (SKU# 1708622A): Intel® Core i5-6300U, 1 DP, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16 750-MD7110-100G (SKU# 1708622B): Intel® Core i7-6600U, 1 DP, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16 750-MD7110-200G (SKU# 1708622C): Intel® Core i5-6300U, 1 HDMI, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16 750-MD7110-300G (SKU# 1708622D): Intel® Core i7-6600U, 1 HDMI, 1 DVI-D, 2 LAN, 2 COM, 6 USB, 1 PCIe x16

MD711-SU – 6th Gen Intel® Core Processor Fanless Medical Computing System

The MD711-SU is the perfect embedded fanless system for your medical computing needs. With a medical-grade anti-microbial finish and downward fin design, cleaning is easy and inhibits bacterial growth. This system has 4kV isolation on LAN, COM, and USB 2.0 ports for transmission without noise and seamless integration with medical equipment. The MD711-SU has vibration resistance and the ability to output to 2 displays simultaneously.

CONTACT US NOW

System *

Memory

2.5″ SATA HDD / SSD

Testing (Only available if memory is included at time of purchase.)

SKU: 1708622 Tags: Medical Computing
