MS-9B05 – Slim Fanless Triple Display Expansion Box PC with Intel Whisky Lake-U Processor

The MS-9B05 is the perfect small form-factor solution for many industrial applications. With its discrete size and fanless design, this system is quiet and fits in tight spaces. Support for up to 3 independent displays makes it robust as a digital signage player. The MS-9B05 is a small yet powerful embedded system.

Additional information

CPU

8th Gen Intel® Whiskey Lake-U Series Processor

Memory Type

260-pin DDR4 SO-DIMM, L1C1 – 2133MHz, L1I1 – 2400MHz

Memory Slots

2

Maximum Memory Supported

32GB

Chipset

Integrated

Integrated Graphics

Intel® UHD Graphics 620

Watchdog Timer

256 levels

Serial ATA (SATA)

1 x SATA III for 2.5" HDD/SSD

LAN Ports

1 x Intel® I219-LM Gigabit PHY LAN, 1 x Intel® I210-AT Gigabit LAN

TPM

Infineon SLB9665TT2.0 (by request)

Extended Interface

1 x M.2 E Key 2230, 1 x M.2 M Key 2242, 1 x MiniPCIe Half/Full Size w/ mSATA, 1 x MiniPCIe w/ Nano-Sim Holder

Rear I/O

2 x RJ45, 2 x COM ports, 1 x DC-In, 1 x SPDIF/Line-out, 1 x Mic/Line-in, 2 x Openings Reserved for Antennas, L1C1 – 2 x USB 3.2 Gen 1, L1I1 – 2 x USB 3.2 Gen 2

Front I/O

4 x USB 2.0, 2 x Openings Reserved for Antennas, L1C1 – 1 x HDMI, 1 x DVI, 1 x DP; L1I1 – 3 x HDMI

Audio

Realtek HD Audio

Power Requirement

DC input 9~36V

Dimensions

10.25" x 7.3" x 1.1" (260mm x 185mm x 27mm)

Operating Temperature

SSD: 14 ~ 122°F (-10 ~ 50°C), HDD: 14 ~ 104°F (-10 ~ 40°C)

Storage Temperature

-4 ~ 176 ˚F (-20 ~ 80 ˚C)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit, Linux Ubuntu/Linux Fedora (by request)

Vibration

IEC61373 Category 1, Class A; Operating: IEC 60068-2-64: 2 Grms, 5 ~ 500 Hz, 1hr/axis (w/ SSD)

Shock

IEC61373 Category 1, Class A; Operating: IEC 60068-2-27: 50G, half sine, 11ms (w/ SSD)

Global P/N / SKU

1708268

Ordering Options

MS-9B05-L1C1 (SKU# 1708268A):
Fanless System with Celeron 4205U, DDR4 2133MHz SO-DIMM, 1 x HDMI, 1 x DVI, 1 x DP, 2 x USB 3.1 Gen 1

MS-9B05-L1I1 (SKU# 1708268B):
Fanless System with i5-8265U, DDR4 2400MHz SO-DIMM, 3 x HDMI, 2 x USB 3.1 Gen 2

Note: TPM available by request. Please contact sales for more information.

Downloads

Datasheet

Ordering Options

MS-9B05-L1C1 (SKU# 1708268A): Fanless System with Celeron 4205U, DDR4 2133MHz SO-DIMM, 1 x HDMI, 1 x DVI, 1 x DP, 2 x USB 3.1 Gen 1 MS-9B05-L1I1 (SKU# 1708268B): Fanless System with i5-8265U, DDR4 2400MHz SO-DIMM, 3 x HDMI, 2 x USB 3.1 Gen 2 Note: TPM available by request. Please contact sales for more information.

MS-9B05 – Slim Fanless Triple Display Expansion Box PC with Intel Whisky Lake-U Processor

The MS-9B05 is the perfect small form-factor solution for many industrial applications. With its discrete size and fanless design, this system is quiet and fits in tight spaces. Support for up to 3 independent displays makes it robust as a digital signage player. The MS-9B05 is a small yet powerful embedded system.

CONTACT US NOW

System

Memory

M.2 SSD

mSATA

2.5″ SSD

Operating System (Only available if a storage device is selected from above.)

Testing (Only available if memory is included at time of purchase.)

SKU: 1708268 Tags: Industrial Automation, Internet of Things (IoT), POS-Kiosk
MSI

Additional information

CPU

8th Gen Intel® Whiskey Lake-U Series Processor

Memory Type

260-pin DDR4 SO-DIMM, L1C1 – 2133MHz, L1I1 – 2400MHz

Memory Slots

2

Maximum Memory Supported

32GB

Chipset

Integrated

Integrated Graphics

Intel® UHD Graphics 620

Watchdog Timer

256 levels

Serial ATA (SATA)

1 x SATA III for 2.5" HDD/SSD

LAN Ports

1 x Intel® I219-LM Gigabit PHY LAN, 1 x Intel® I210-AT Gigabit LAN

TPM

Infineon SLB9665TT2.0 (by request)

Extended Interface

1 x M.2 E Key 2230, 1 x M.2 M Key 2242, 1 x MiniPCIe Half/Full Size w/ mSATA, 1 x MiniPCIe w/ Nano-Sim Holder

Rear I/O

2 x RJ45, 2 x COM ports, 1 x DC-In, 1 x SPDIF/Line-out, 1 x Mic/Line-in, 2 x Openings Reserved for Antennas, L1C1 – 2 x USB 3.2 Gen 1, L1I1 – 2 x USB 3.2 Gen 2

Front I/O

4 x USB 2.0, 2 x Openings Reserved for Antennas, L1C1 – 1 x HDMI, 1 x DVI, 1 x DP; L1I1 – 3 x HDMI

Audio

Realtek HD Audio

Power Requirement

DC input 9~36V

Dimensions

10.25" x 7.3" x 1.1" (260mm x 185mm x 27mm)

Operating Temperature

SSD: 14 ~ 122°F (-10 ~ 50°C), HDD: 14 ~ 104°F (-10 ~ 40°C)

Storage Temperature

-4 ~ 176 ˚F (-20 ~ 80 ˚C)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit, Linux Ubuntu/Linux Fedora (by request)

Vibration

IEC61373 Category 1, Class A; Operating: IEC 60068-2-64: 2 Grms, 5 ~ 500 Hz, 1hr/axis (w/ SSD)

Shock

IEC61373 Category 1, Class A; Operating: IEC 60068-2-27: 50G, half sine, 11ms (w/ SSD)

Global P/N / SKU

1708268

Ordering Options

MS-9B05-L1C1 (SKU# 1708268A):
Fanless System with Celeron 4205U, DDR4 2133MHz SO-DIMM, 1 x HDMI, 1 x DVI, 1 x DP, 2 x USB 3.1 Gen 1

MS-9B05-L1I1 (SKU# 1708268B):
Fanless System with i5-8265U, DDR4 2400MHz SO-DIMM, 3 x HDMI, 2 x USB 3.1 Gen 2

Note: TPM available by request. Please contact sales for more information.

Downloads

Datasheet

Ordering Options

MS-9B05-L1C1 (SKU# 1708268A): Fanless System with Celeron 4205U, DDR4 2133MHz SO-DIMM, 1 x HDMI, 1 x DVI, 1 x DP, 2 x USB 3.1 Gen 1 MS-9B05-L1I1 (SKU# 1708268B): Fanless System with i5-8265U, DDR4 2400MHz SO-DIMM, 3 x HDMI, 2 x USB 3.1 Gen 2 Note: TPM available by request. Please contact sales for more information.
