NF9E-Q77 - Mini-ITX Motherboard with Intel Q77 Express Chipset for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

NF9E-Q77 – Mini-ITX Motherboard with Intel Q77 Express Chipset

for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

Recommended Processors: 3rd generation Intel Core processors (22nm process technology) - Intel Core i7-3770 (8M Cache, up to 3.9 GHz); 77W - Intel Core i5-3550S (6M Cache, up to 3.7 GHz); 65W - Intel Core i3-3220 (3M Cache, 3.3 GHz); 55W - Intel Pentium G2120 (3M Cache, 3.1 GHz); 65W

Additional information

CPU

Intel 3rd Generation Core i3 / i5 / i7 Desktop Processors (see addtional information tab for recommended processors)

CPU Socket

LGA 1155

Memory Slots

2 x 204-pin SO-DIMM

Maximum Memory Supported

16GB

Memory Standard

DDR3 1066 / 1333 MHz SDRAM

ECC Memory Supported

No

Onboard Memory

No

Dual Channel Memory Support

Yes

Chipset

Intel Q77 Express Chipset

BIOS

AMI 64M DIP Flash ROM

Video Chipset

Intel HD Graphics (Based on CPU Type)

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

2 x SATA 6.0 Gbps, 4 x SATA 3.0 Gbps Supports AHCI, RAID 0,1,5,10

Audio Chipset

Realtek ALC662 6-CH HD Audio CODEC

Gigabit LAN Ports

2 x Gigabit Ethernet Controllers (1 x Intel 82579LM with iAMT 8.0, 1 x Intel 82574L)

GPIO Port

1 x GPIO Header (4 in / 4 out)

PCI Express Mini-Card (Mini-PCIe)

1 x Half size PCIe mini card socket

PCIe Socket

1 x PCIe (x16) – (Supports Gen 3.0 with 3rd Generation processors only)

Serial (COM) Port

1 x RS-232 (rear I/O), 1 x RS-232/422/485 (rear I/O)

USB Port

10 x USB (2 x USB 3.0 on rear I/O, 4 x USB 2.0 on rear I/O, 2 x USB 3.0 via oboard header, 2 x USB 2.0 via oboard header,

HDMI

1 x HDMI (rear I/O)

LVDS

1 X 24-bit Dual Channel LVDS header

VGA

1 x VGA (rear I/O)

Audio

1 x Line In, Line Out, Mic In (rear I/O), 1 x Front Panel via onboard header

HDTV-Out

via HDMI and DVI-D

TV-Out

via HDMI and DVI-D

Approximate Weight

0.88 lbs (0.4 Kg)

Dimensions

W:6.7" x D:6.7" (170 mm x 170 mm)

Operating Temperature

0ºC ~ 60 ºC (32 ºF ~ 140 ºF)

Storage Temperature

-20 ~ 80 °C (-4 ~176 °F)

Relative Humidity

10% to 90% (non condensing)

OS Software Supported

All popular Operating System Software including: Linux, Windows XP / Vista / 7. Not all features are guaranteed to work under every O/S

Global P/N / SKU

2808312

Ordering Options

NF9E-Q77 (SKU# 2808312):

Mini-ITX Motherboard with Intel Q77 Express Chipset for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

Product Drivers

Product Drivers

Ordering Options

NF9E-Q77 (SKU# 2808312): Mini-ITX Motherboard with Intel Q77 Express Chipset for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

NF9E-Q77 – Mini-ITX Motherboard with Intel Q77 Express Chipset

for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

Recommended Processors:
3rd generation Intel Core processors (22nm process technology)
– Intel Core i7-3770 (8M Cache, up to 3.9 GHz); 77W
– Intel Core i5-3550S (6M Cache, up to 3.7 GHz); 65W
– Intel Core i3-3220 (3M Cache, 3.3 GHz); 55W
– Intel Pentium G2120 (3M Cache, 3.1 GHz); 65W

CONTACT US NOW

Out of stock

Additional information

CPU

Intel 3rd Generation Core i3 / i5 / i7 Desktop Processors (see addtional information tab for recommended processors)

CPU Socket

LGA 1155

Memory Slots

2 x 204-pin SO-DIMM

Maximum Memory Supported

16GB

Memory Standard

DDR3 1066 / 1333 MHz SDRAM

ECC Memory Supported

No

Onboard Memory

No

Dual Channel Memory Support

Yes

Chipset

Intel Q77 Express Chipset

BIOS

AMI 64M DIP Flash ROM

Video Chipset

Intel HD Graphics (Based on CPU Type)

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Serial ATA (SATA)

2 x SATA 6.0 Gbps, 4 x SATA 3.0 Gbps Supports AHCI, RAID 0,1,5,10

Audio Chipset

Realtek ALC662 6-CH HD Audio CODEC

Gigabit LAN Ports

2 x Gigabit Ethernet Controllers (1 x Intel 82579LM with iAMT 8.0, 1 x Intel 82574L)

GPIO Port

1 x GPIO Header (4 in / 4 out)

PCI Express Mini-Card (Mini-PCIe)

1 x Half size PCIe mini card socket

PCIe Socket

1 x PCIe (x16) – (Supports Gen 3.0 with 3rd Generation processors only)

Serial (COM) Port

1 x RS-232 (rear I/O), 1 x RS-232/422/485 (rear I/O)

USB Port

10 x USB (2 x USB 3.0 on rear I/O, 4 x USB 2.0 on rear I/O, 2 x USB 3.0 via oboard header, 2 x USB 2.0 via oboard header,

HDMI

1 x HDMI (rear I/O)

LVDS

1 X 24-bit Dual Channel LVDS header

VGA

1 x VGA (rear I/O)

Audio

1 x Line In, Line Out, Mic In (rear I/O), 1 x Front Panel via onboard header

HDTV-Out

via HDMI and DVI-D

TV-Out

via HDMI and DVI-D

Approximate Weight

0.88 lbs (0.4 Kg)

Dimensions

W:6.7" x D:6.7" (170 mm x 170 mm)

Operating Temperature

0ºC ~ 60 ºC (32 ºF ~ 140 ºF)

Storage Temperature

-20 ~ 80 °C (-4 ~176 °F)

Relative Humidity

10% to 90% (non condensing)

OS Software Supported

All popular Operating System Software including: Linux, Windows XP / Vista / 7. Not all features are guaranteed to work under every O/S

Global P/N / SKU

2808312

Ordering Options

NF9E-Q77 (SKU# 2808312):

Mini-ITX Motherboard with Intel Q77 Express Chipset for 3rd Generation Intel Core i3/i5/i7 Desktop Processors

Product Drivers

Product Drivers

Ordering Options

NF9E-Q77 (SKU# 2808312): Mini-ITX Motherboard with Intel Q77 Express Chipset for 3rd Generation Intel Core i3/i5/i7 Desktop Processors
