SI-323-NM – Fanless AMD Ryzen Embedded System

The SI-323-NM is a powerful compact fanless system. It uses hardware acceleration to output 4K resolution at 60Hz refresh rate on up to 3 independent displays. The system's small design allows for deployment in space constrained areas.

Additional information

CPU

AMD Ryzen Embedded R1606G

Memory Type

260-pin DDR4 2400MHz SO-DIMM

Memory Slots

2

Maximum Memory Supported

32 GB

Chipset

AMD Integrated SoC

Integrated Graphics

AMD Radeon Vega 3 Graphics

Watchdog Timer

256 segments, 0,1,2…255 sec/min

Video

3 x HDMI 2.0

LAN Ports

2 x Realtek RTL8111H Gigabit LAN

Extended Interface

1 x Mini PCIe, 1 x M.2 M-Key (2280, SATA signal only), 1 x M.2 B-Key (2230), 1 x SIM Card slot

Rear I/O

3 x HDMI 2.0, 2 x USB 3.0, 1 x USB 2.0, 2 x RJ45 (LAN), 1 x RJ45 (RS232 Serial), 1 x Line-Out

Audio

Realtek HD Audio

Power Requirement

DC input 12V

Dimensions

215.8mm x 164mm x 45mm

Operating Temperature

32 ~ 113°F (0 ~ 45°C)

Storage Temperature

-4 ~ 176 ˚F (-20 ~ 80 ˚C)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit

Global P/N / SKU

1708258

Ordering Options

SI-323-NM (SKU# 1708258):
AMD Ryzen R1606G Fanless Embedded System

Ordering Options

SI-323-NM (SKU# 1708258): AMD Ryzen R1606G Fanless Embedded System

SI-323-NM – Fanless AMD Ryzen Embedded System

The SI-323-NM is a powerful compact fanless system. It uses hardware acceleration to output 4K resolution at 60Hz refresh rate on up to 3 independent displays. The system’s small design allows for deployment in space constrained areas.

CONTACT US NOW

System *

Memory

M.2 SATA SSD

Operating System (Only available if a storage device is selected from above.)

Testing (Only available if memory is included at time of purchase.)

SKU: 1708258 Tags: Industrial Automation, POS-Kiosk
iBase

Additional information

CPU

AMD Ryzen Embedded R1606G

Memory Type

260-pin DDR4 2400MHz SO-DIMM

Memory Slots

2

Maximum Memory Supported

32 GB

Chipset

AMD Integrated SoC

Integrated Graphics

AMD Radeon Vega 3 Graphics

Watchdog Timer

256 segments, 0,1,2…255 sec/min

Video

3 x HDMI 2.0

LAN Ports

2 x Realtek RTL8111H Gigabit LAN

Extended Interface

1 x Mini PCIe, 1 x M.2 M-Key (2280, SATA signal only), 1 x M.2 B-Key (2230), 1 x SIM Card slot

Rear I/O

3 x HDMI 2.0, 2 x USB 3.0, 1 x USB 2.0, 2 x RJ45 (LAN), 1 x RJ45 (RS232 Serial), 1 x Line-Out

Audio

Realtek HD Audio

Power Requirement

DC input 12V

Dimensions

215.8mm x 164mm x 45mm

Operating Temperature

32 ~ 113°F (0 ~ 45°C)

Storage Temperature

-4 ~ 176 ˚F (-20 ~ 80 ˚C)

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Windows 10 64-bit

Global P/N / SKU

1708258

Ordering Options

SI-323-NM (SKU# 1708258):
AMD Ryzen R1606G Fanless Embedded System

Ordering Options

SI-323-NM (SKU# 1708258): AMD Ryzen R1606G Fanless Embedded System
