Additional information
| CPU | Intel® Celeron J6412 |
|---|---|
| Memory Type | DDR4 2133/2400/3200Mhz |
| Memory Slots | 1 |
| Maximum Memory Supported | 32GB |
| Integrated Graphics | Intel® Gen10 UHD Graphics |
| Watchdog Timer | Programmable 255 levels timer interval, from 1~255 sec/min |
| Serial ATA (SATA) | 1 x SATA III |
| Video | 1 x HDMI (up to 4096×2160@60hz) |
| LAN Ports | 2 x Intel® L226V GbE (10/100/1000 Mbps) |
| Audio | 2 x 1.5W speakers (optional) Realtek® ALC888S HD Audio codec 4Ω3W speakerx2 |
| Extended Interface | 1 x Mini-PCIe slot (PCIe/ USB2.0 signal supported), 1 x M.2 2230 slot (PCIe/ USB2.0 signal supported), 1 x M.2 2242 slot (SATA signal supported), 1 x SIM socket for 3G/4G |
| External I/O | 1 x Mini PCIe slot w/ 1 x SIM card slot, 1 x RS232/RS422/RS485(COM1), 1 x RS232(default)/RS485(Jumper), 2 x USB2.0, 2 x USB3.1, 2 x RJ45, 1 x HDMI, 1 x Remote ON-OFF |
| Internal I/O | 1 x 8bit GPIO 3.3V(jumper)/5V(default) power, 2 x RS232, 2 x USB2.0 (For Touch), 1 x SATA3.0/Power 5V for HDD |
| Display | 15" TFT LCD Panel |
| Resolution | 1024×768, 4:3 aspect ratio |
| Luminance | 300 cd/m² |
| Touch | Industrial-grade true-flat 5-wire resistive touchscreen |
| Contrast Ratio | 800 |
| Viewing Angle (U/D/R/L) | 80°/80°/80°/80° |
| Backlight Lifetime | 30,000 hours |
| Mounting | Panel Mount, Wall and VESA-mount (75 x 75mm) |
| Chassis | Aluminum for front Panel and heat-sink, SECC for Rear Cover |
| Cutout | 341.4 x 265.4mm |
| Ingress Protection | Front Panel IP66 |
| Weight | 4.5KG |
| Dimensions | 351.6 x 275.6 x 68.4mm |
| Operating Temperature | -10 ~ 60 °C |
| Storage Temperature | -40°C ~ 70°C |
| Relative Humidity | 5 ~ 95% (non-condensing) |
| Random Vibration | 5~500Hz, 1Grms (HDD) operation, 5~500Hz, 2Grms (SSD) operation |
| Sine Vibration | 5~500Hz, 2G Non-operation |
| Shock | 10g 11ms operation, 30g 11ms Non-operation |
| Power | DC 12~36V via 1 x Power Connector (2P Phoenix) |
| Certification | CCC/CE/FCC |
| Global P/N / SKU | 2907841 |
