Stormbox-60E - 4th Generation Intel Core Desktop Processor-based Video Wall Player with AMD Radeon E8860 Graphics and 12 HDMI

4th Generation Intel Core Desktop Processor-based Video Wall Player with AMD Radeon E8860 Graphics and 12 HDMI

System *

Processor (CPU) *

Memory *

1st Hard Drive(HDD) / Solid State *

2nd Hard Drive(HDD) / Solid State *

Addon Card(s) *

Testing *

Operating System *

SKU: 1708159 Categories: , Tag:

Description

The 4th Generation Intel Core processor-based Stormbox-60E with super-high 8K video wall player is an innovative digital signage player built specifically for multi-screen video wall display applications. The Starbox-60E supports up to twelve display outputs and features Multiple-Display Matrix Technology for flexible configuration and resolution settings, hardware EDID emulation and bezel adjustment. This aesthetically designed player offers awesome 3D graphics performance with resolutions up to 7680 x 3600 or 11520 x 2400. The system also integrates iSMART technology featuring power on/off scheduling, power resume function, low-temperature guardian and intelligent OS recovery that reduces maintenance cost, enhances system stability and ensures long-term reliability.

Additional Information

Memory

4 x 240-pin DDR3 1600 MHz (select from dropdown options)

Gigabit LAN Ports

2 x Gigabit Ethernet Controllers (1 x Intel i218LM, 1 x Realtek RTL8111G-CG)

Form Factor

Digital Signage / Video Wall Player

Audio

1 x Line In, Line Out, Mic In

CPU Socket

LGA 1150

Power Supply

1 x 250 Watt PSU (included)

OS Software Supported

All popular Operating System Software including: Linux, Windows 7, Windows 8.1 Not all features are guaranteed to work under every O/S

Board

Not Sold Separately

Audio Chipset

Realtek High Definition Audio

PCI Express Mini-Card (Mini-PCIe)

2 x Mini-PCIe

Maximum Memory Supported

32GB

USB Port

4 x USB 3.0

Chassis

Not Sold Separately

Global P/N / SKU

1708159

CPU

4th Generation Intel Core i3/i5/i7 Desktop Processors up to 3.5GHz (select from dropdown options)

10/100(Fast) LAN

via Gigabit LAN connections

SATA Hard Drive

1 x mSATA, 2 x SATA 3.0 2.5" HDD/SSD dock (supports RAID 1) - Select from dropdown options

Video Chipset

Discrete AMD Radeon E8860 graphics

Dual Channel Memory Support

Yes

Manufacturer

iBase

2.5" Bay

2 x SATA 3.0 2.5" HDD/SSD Dock (supports RAID 1)

MFR P/N

SI-60E

Power Management

EuP/ErP power saving

Video Memory

2GB GDDR5

Chipset

Intel Q87 PCH

Dimensions

W: 16.22" x D: 12.2" x H: 1.85" (412mm x 310mm x 47mm)

LEDs

1 x Power On/Off, 1 x HDD/SSD Activity LED

Video Resolution

up to 8K

Switches

1 x Power button

Construction

SGCC

BIOS

UEFI BIOS

HDMI

12 x HDMI

Additional I/O

1 x RS232, 1 x DVI-I for Console

Operating Temperature

0ºC ~ 45ºC (32 ºF ~ 113 ºF)

Watchdog Timer

256 Segments, 0, 1, 2...255 (sec/min.)

Ordering Options

Starbox-60E (SKU# 1708159):
4th Generation Intel Core Desktop Processor-based Video Wall Player with AMD Radeon E8860 Graphics and 12 HDMI

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Storage Temperature

-20 ºC ~ 80 ºC (-4 ºF ~ 176 ºF)

Approximate Weight

11.9 lbs (5.4Kg)

Product Features

Dimensions:W: 16.22" x D: 12.2"  x H: 1.85" (412mm x 310mm x 47mm)

CPU:4th Generation Intel Core-i7, Core-i5 and Core i3 processors (choose from dropdown options)

BIOS: LGA1150 /  UEFI BIOS

Memory:4 x 240-pin DDR3 1600 MHz up to 32GB (choose from dropdown options)

Expansion: 2 x PCI Express Mini-Card Socket

Storage Controller:1 x mSATA, 2 SATA 3.0 2.5" HDD/SSD dock (supports RAID 1)

Video: AMD E8860 supporting AMD eyefinity technology3, 12 x HDMI

USB:4 x USB 3.0

Serial Ports:1 x RS232

TV-Out:via HDMI

LAN:2 x Gigabit Ethernet Controllers (1 x Intel i218LM, 1 x Realtek RTL8111G-CG)

Power: 1 x 250 Watt PSU (included)

Additional Expansion

1 x mSATA

Power Connector

1 x AC Power Outlet

Starbox-60E (SKU# 1708159): 4th Generation Intel Core Desktop Processor-based Video Wall Player with AMD Radeon E8860 Graphics and 12 HDMI
