MS-98M3 – 3.5 Inch Intel® Tiger Lake-UP3 Wide Temperature SBC

The MS-98M3 is an ultra low power 3.5" SBC equipped with an Intel® Tiger Lake-UP3 processor. This board is compact and robust with a wide temperature range of -40 ~ 70°C, making it capable of use in demanding environments. With quadruple independent display support, the MS-98M3 is an excellent embedded industrial solution.

Additional information

CPU

Intel® IoTG Tiger Lake-UP3 Processors

Memory Type

260-pin DDR4 3200MHz SO-DIMM

Memory Slots

2

Maximum Memory Supported

64GB

Integrated Graphics

Intel® Iris® Xe for i7 / i5, Intel® UHD Graphics for i3 / Celeron

Watchdog Timer

256-Level

Video

2 x LVDS / eDP, 1 x HDMI, 1 x DP

LAN Ports

2 x Intel® I225-IT 2.5 GbE LAN (LAN Speed running at 1000/100/10Mbps when OP TEMP over 70°C)

Serial ATA (SATA)

1 x SATA III

GPIO Interface

16-bits (8 x GPI; 8 x GPO), 5V

TPM

Infineon SLB9670VQ2.0

Extended Interface

1 x M.2 M-Key (2280, PCIe Gen4 x4 NVMe), 1 x M.2 B-Key (2242/3042, SATA 3.0, PCIe x1, USB 2.0, w/NANO SIM-Holder), 1 x M.2 E-Key (2230, PCIe x1, USB 2.0)

Rear I/O

1 x DP, 1 x HDMI, 4 x USB 3.2 Gen 2, 2 x 2.5 GbE LAN

Audio

Realtek® ALC888-VD2-GR HD Audio Codec (Co-lay ALC897)

Power Requirement

DC input 12~24V

Dimensions

5.75" x 4.01" (146mm x 102mm)

Operating Temperature

-40 ~ 70°C (w/Turbo disabled) – Note* Thermal w/ Airflow:0.7m/s; the standard thermal solution only supports TDP up to 15W. 3. -40 ~ 85°C by request

Storage Temperature

-40 ~ 85 °C

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Linux Ubuntu 22.04 (64-bit, by request),Linux Yocto Project 3.1 (64-bit, by request), Windows 10 IoT Enterprise 2019 LTSC (64-bit, RS5), Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2), Windows 11 IoT Enterprise (64-bit, 21H2, Pre-scan)

Global P/N / SKU

3308926

Ordering Options

3308926A: MS-98M3/609-98M3-010/809-98M3-014 with Core i7-1185GRE

3308926B: MS-98M3/609-98M3-010/809-98M3-015 with Core i5-1145GRE

3308926C: MS-98M3/609-98M3-010/809-98M3-016 with Core i3-1115GRE



Cables included: DC Power Cable (200mm), COM port cable (150mm), USB Cable (150mm), SATA Cable with Power (230mm)



Datasheet

Datasheet

Ordering Options

3308926A: MS-98M3/609-98M3-010/809-98M3-014 with Core i7-1185GRE 3308926B: MS-98M3/609-98M3-010/809-98M3-015 with Core i5-1145GRE 3308926C: MS-98M3/609-98M3-010/809-98M3-016 with Core i3-1115GRE   Cables included: DC Power Cable (200mm), COM port cable (150mm), USB Cable (150mm), SATA Cable with Power (230mm)

MS-98M3 – 3.5 Inch Intel® Tiger Lake-UP3 Wide Temperature SBC

The MS-98M3 is an ultra low power 3.5″ SBC equipped with an Intel® Tiger Lake-UP3 processor. This board is compact and robust with a wide temperature range of -40 ~ 70°C, making it capable of use in demanding environments. With quadruple independent display support, the MS-98M3 is an excellent embedded industrial solution.

CONTACT US NOW

Board *

Memory

M.2 NVMe SSD

2.5″ SATA SSD

Operating System (Only available if a storage device is selected from above.)

Testing (Only available if memory is included at time of purchase.)

SKU: 3308926 Tags: Harsh Environment, Industrial Automation, Internet of Things (IoT), Long Life, Oil and Gas, small form factor, Wide Temperature

Additional information

CPU

Intel® IoTG Tiger Lake-UP3 Processors

Memory Type

260-pin DDR4 3200MHz SO-DIMM

Memory Slots

2

Maximum Memory Supported

64GB

Integrated Graphics

Intel® Iris® Xe for i7 / i5, Intel® UHD Graphics for i3 / Celeron

Watchdog Timer

256-Level

Video

2 x LVDS / eDP, 1 x HDMI, 1 x DP

LAN Ports

2 x Intel® I225-IT 2.5 GbE LAN (LAN Speed running at 1000/100/10Mbps when OP TEMP over 70°C)

Serial ATA (SATA)

1 x SATA III

GPIO Interface

16-bits (8 x GPI; 8 x GPO), 5V

TPM

Infineon SLB9670VQ2.0

Extended Interface

1 x M.2 M-Key (2280, PCIe Gen4 x4 NVMe), 1 x M.2 B-Key (2242/3042, SATA 3.0, PCIe x1, USB 2.0, w/NANO SIM-Holder), 1 x M.2 E-Key (2230, PCIe x1, USB 2.0)

Rear I/O

1 x DP, 1 x HDMI, 4 x USB 3.2 Gen 2, 2 x 2.5 GbE LAN

Audio

Realtek® ALC888-VD2-GR HD Audio Codec (Co-lay ALC897)

Power Requirement

DC input 12~24V

Dimensions

5.75" x 4.01" (146mm x 102mm)

Operating Temperature

-40 ~ 70°C (w/Turbo disabled) – Note* Thermal w/ Airflow:0.7m/s; the standard thermal solution only supports TDP up to 15W. 3. -40 ~ 85°C by request

Storage Temperature

-40 ~ 85 °C

Relative Humidity

10 ~ 90% (non-condensing)

OS Software Supported

Linux Ubuntu 22.04 (64-bit, by request),Linux Yocto Project 3.1 (64-bit, by request), Windows 10 IoT Enterprise 2019 LTSC (64-bit, RS5), Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2), Windows 11 IoT Enterprise (64-bit, 21H2, Pre-scan)

Global P/N / SKU

3308926

Ordering Options

3308926A: MS-98M3/609-98M3-010/809-98M3-014 with Core i7-1185GRE

3308926B: MS-98M3/609-98M3-010/809-98M3-015 with Core i5-1145GRE

3308926C: MS-98M3/609-98M3-010/809-98M3-016 with Core i3-1115GRE



Cables included: DC Power Cable (200mm), COM port cable (150mm), USB Cable (150mm), SATA Cable with Power (230mm)



Datasheet

Datasheet

Ordering Options

3308926A: MS-98M3/609-98M3-010/809-98M3-014 with Core i7-1185GRE 3308926B: MS-98M3/609-98M3-010/809-98M3-015 with Core i5-1145GRE 3308926C: MS-98M3/609-98M3-010/809-98M3-016 with Core i3-1115GRE   Cables included: DC Power Cable (200mm), COM port cable (150mm), USB Cable (150mm), SATA Cable with Power (230mm)
